SubSystems
OptionsandDetails
PDU’s
EnvironmentalMonitoring
DCIM
EnergyMonitoring
Security
Internal CommsLinks
External CommsLinks
Tier Rating
Schneider Electric/ APCZeroUSinglePhaseor ThreePhase16Aor 32A.
Basic,Meteredor SwitchedConfigurationsAvailable.
Schneider Electric / APCNetbotz570EnvironmentalMonitoringSystems.
Sensor include, Temperature, Humidity,Water Leak, Vibration, Volt FreeContacts.
SystemsScaled toSuit Individual Client Requirements.
Schneider Electric / APCStruxureWareDataCentreExpert BasePlatform.
DCIMS/WModules includeOperations, Capacity, Change, Energy&Optimization.
10 / 100 / 200UserGranular LicenseOptions.
Schneider ElectricStruxureWarePowerMonitoringExpert.
LVPanels fittedwithSchneider ElectricPM750and IONMeters to suit design.
Schneider ElectricPelco IPCameraSystems - Internal / External, Day /Night. Fixed / PTZ
configurationsOptions.
PelcoScalableDVRSystems.
ACT IPAccessControl SystemorCustomer SiteSpecificSystem Installed.
Optional Intruder AlarmSystems.
Cat6/6A24or 48Port RJ45panel topanel linkwiredbetweencommsand rear of server
cabinets.
8 / 16 / 32 / 48 / 96MMor SMFibrepanel topanel linkwiredbetweencommsand rear of
server cabinets.
All SystemareDesigned toSuit.
Example Arrangement 10Pair VoiceCable, 8core50/125MMOM3grade fibreSC
connections.
All SystemareDesigned toSuit.
All SystemareDesigned toSuit.
BaseConfigurationTier 2.
EnhancedConfigurationTier 3.
