SubSystems
OptionsandDetails
Housing
Floor Finish
Dimension/Weight
Cooling
ChilledWater
Airflow
FireSuppression
UPS
By-PassSwitch
Critical Power
PodLVDistributionBoard
General Power
StandbyGenerators
Cabinets
Constructed from100 x 50 x 3RHSwith4.5O/Pdurbar plate floor, fully insulated100mm
thickmineral wool fill walls, pre-finished internal white, external colour coat plastersol pre-
finished surface.
Standard - TreadPlatewithAntistaticPolyflor AntistaticVinyl
Enhanced -HeavyDuty (4.2KNpoint load), 600 x 600 tile format completewithbonded
antistatic vinyl finish.
StandardsSizes include:
Modular 20 foot 6m(L) x 3.4m (H) x 3.5m (W) - 10,000KG to20,000KG*
Modular 30 foot 9m(L) x 3.4m (H) x 3.5m (W) - 20,000KG to30,000KG*
Modular 40 foot 12m(L) x 3.4m (H) x 3.5m (W) - 30,000KG to40,000KG*
Note -Containerised versionall 2.4m (W). *EstimatedFully loadWeightsOnly.
Schneider Electric / APC InRow rackmounted format 300mm/ 600mmWide x 1070mm
Deep x 42U, 18Kw to60kWCoolingCapacity.
USystemsRearDoor Systems10kW to60kWPer Rack
GEAHeat ExchangersPerimeterCooling20kW to100kWPerCRACUnit
Freecool®EvaporativeDirect FreeAirCooling30kW to120kWper pod
Excool Indirect EvaporativeFreeAirCooling60kW to200kWper pod.
WhereChilledWater SystemsaredeployedWorkspaceTechnology canprovideachoice
of Chillers, AdiabaticandDrycoolersorCoolingTower Technology.
Full AisleContainment systems to suit cooling.
RackBlankingPanels.
KoldlokBrushSealingSystems.
FM200, Novecand IG55Optionsavailable.
VESDAEarlySmokeDetectionalarmOptions.
Extraction&VentilationSystems.
Schneider Electric / APCSymmetraPX48 / 96 /160 modular 42U rackmountedUPS
configurable in16kW incrementsplus batteryautonomy to suit.
APCSymmetraPX250/500 /modular 42U rackmountedUPSconfigurable in25kW
increments, plusbatteryautonomy to suit.
N+1PowerModulesAvailable.
IntegratedUPSExternal BypassSwitch.
CustomSwitchgear Bypass.
Dual resilient Form4Type2ThreePhasePowerDistributionBoard (PDU) to rated to
matchUPScompletewith16Aand32ASingleor Threephasecommando sockets to suit
client requirements.
Endof Aisleor In-RowOptional Available.
Schneider ElectricForm4Type2/6 - 125kW / 250kW / 500kW / 750kW / 1000kWLV Three
Phasedistributionboards to suit kWcapacity.
Boards fittedwithPM750 full functionModbusMeter Systems.
Optional PowerQuality IONMeters fitted.
CleanersSockets4 to6per Pod.General Power.
T5or LEDLowEnergyLightingSystemswithPIROperation.
125kVA / 250kVA/ 500kVA / 750kVA / 1000kVAGenerator Systems toSuit.
AutomaticTransfer SwitchSystems.
AcousticsPackage toSuit SiteRequirements. 12HourDayTank.
CustomExtendedFuel SystemsToSuit.
Schneider Electric / APCSX42U to48U 750mmor 600mmwideby1070mmdeepserver
grademeshed front andmeshed split rear doors.
Full set of CableandRackManagement Accessories.
Schneider ElectricRackHIDKitOptions.
