Specifications
NetBotz 570
Product SKUS
NetBotz Rack Monitor 570
NBRK0570
Technical Specifications
Includes
Installation Guide; Documentation CD; Rack Mounting Brackets; USB Cable; Temperature/Humidity Sensor;
Country-Specific Detachable Power Cord
Housing
Rack-mount, 43.5 mm H x 432 mm W x 93 mm D
Indicators
Alert; Power; Network Link
APC Universal Sensors
Supported
Temperature; Temperature / Humidity; Door Contact; Smoke; Spot Leak; Vibration; Dry Contact; 0-5V; 4-20mA
Sensor Pods Supported
Room Sensor Pod (NBPD0155); Rack Sensor Pod (NBPD0150) ; Wireless Sensor Pod 180 (NBPD0180)
Rack Access Pods
Supported
NetBotz Rack Access Pod 170 (NBPD0170)
External Cameras
Supported
NetBotz Camera Pod 160; Pelco IP Camera Families: Sarix, Spectra IV IP, Spectra Mini IP;
IP110 Camclosure; IP3701; and CCTV Cameras integrated through the NetBotz CCTV Adapter Pod
Connectors
Ethernet: (1) 10/100 Base-T Ethernet Port; Power: AC Line Inlet Port 100-240 V AC, 50/60 Hz; (6) APC Universal
Sensor Ports; (1) USB Configuration Port – Style B; (4) USB Ports – Style A; (1) A-Link
Port; (1) Voltage Output Port; (2) Relay Output Ports; (4) 4-20mA Input Ports; (1) Beacon Port;
(1) Rope Leak Sensor Port; (1) RS-485 Modbus connection
Protocols
TCP/IP; HTTP; HTTPS; SMTP; SNMP v1, v2c, and v3; DHCP; DNS; Socks v4 or V5 Proxy Server; A-Link
Management Interface
Internet Explorer
v 5.5 or later; Mozilla
1.3 or later; Firefox
2.0 or later;
NetBotz Advanced View Software; StruxureWare Data Center Expert
Client System
Requirements
Microsoft Windows 7 Pro and Ultimate; Vista Business and Enterprise; XP SP2-3; Red Hat EL4 and EL5
Use of Advanced View interface requires a one-time download of the Sun
Java Runtime Environment
.
Operating Environment
Temperature: 0 - 45
C (32 – 113
F); Relative Humidity: 10-95% (non-condensing);
For indoor use only, not designed for use in corrosive or caustic environments.
Regulatory Approvals
CE; UL; c-UL; VDE; IRAM; NOM; GOST; FCC 47 CFR Part 15 Class A; ICES-003 Class A; AS/NZS CISPR 22; VCCI
Class A; Low Voltage Directive 2006/95/EC; EMC Directive 2004/108/EC
Standard Hardware
Warranty
Two Years
Extended Warranty
WNBWN002
Base – 2 Year Software Support Contract (NBRK0451//NBRK0570)
WNBWN004
Extension – 1 Year Software Support Contract and 1 Year Hardware Warranty
(NBRK0451/NBRK0570)
Installation Services
WCONFIG1NB-NB-10
NetBotz Configuration Service in ISX Designer 1
WCONFIG2NB-NB-10
NetBotz Configuration Service in ISX Designer 2
©
